AISC 358-16 is the American standard for prequalified connections in steel special and intermediate moment frames used in seismic design. It sets the design, detailing, fabrication and quality criteria for each connection type, so engineers can use these connections without project-specific qualification testing.

What is AISC 358-16?

ANSI/AISC 358-16, Prequalified Connections for Special and Intermediate Steel Moment Frames for Seismic Applications, is published by the American Institute of Steel Construction. It specifies design, detailing, fabrication and quality criteria for beam-to-column connections that are prequalified under the AISC Seismic Provisions (AISC 341) for special moment frames (SMF) and intermediate moment frames (IMF). The connections count as prequalified only when designed and built to this standard.

When to use it

  • When designing a special or intermediate steel moment frame for seismic loads
  • When choosing a moment connection type and checking its limits of use
  • When preparing connection details, shop drawings and weld or bolting requirements
  • When reviewing fabrication and erection submittals for moment frame connections
  • When planning quality control and inspection of seismic moment connections

What’s included

The download is a PDF of the ANSI/AISC 358 standard for prequalified connections for steel moment frames. It covers design, detailing, fabrication and quality criteria for connections prequalified in accordance with the AISC Seismic Provisions for SMF and IMF. The standard also makes clear that other connection types can be used when qualification is shown to the authority having jurisdiction.

How to use it

  1. Confirm the seismic force-resisting system and whether it is an SMF or IMF under AISC 341.
  2. Check which edition of AISC 358 your building code and project specification reference.
  3. Select a connection type and confirm your beam and column sizes fall within its prequalification limits.
  4. Follow the design procedure for that connection step by step.
  5. Detail the connection as the standard requires, including welds, bolts and any plates.
  6. Carry the fabrication and quality requirements into the specifications and shop drawing review.

Tips

  • Read the limits of use for each connection first. Outside them, the connection is no longer prequalified.
  • Coordinate with your fabricator early. Some connections suit certain shops better than others.
  • Use AISC 358 with AISC 341 and AISC 360. It is not a standalone design code.

Related templates and guides

Frequently asked questions

What is AISC 358?

AISC 358 is the AISC standard that lists prequalified beam-to-column connections for steel special and intermediate moment frames in seismic applications. For each connection it gives design procedures, limits of use, detailing rules and fabrication and quality requirements.

What is a prequalified connection?

A prequalified connection is one that has been tested and reviewed enough that it can be used in a seismic moment frame without new qualification testing for each project, as long as it is designed and built within the limits of the standard.

What is the difference between AISC 341 and AISC 358?

AISC 341, the Seismic Provisions, sets the requirements for seismic force-resisting systems, including what moment frame connections must achieve. AISC 358 provides specific connection details that are prequalified to meet those requirements. The two are used together.

Which connections are covered in AISC 358-16?

The 2016 edition includes connections such as the reduced beam section (RBS), bolted unstiffened and stiffened extended end-plate, bolted flange plate, and welded unreinforced flange-welded web, along with several proprietary connection types.

Is AISC 358-16 the latest edition?

No. AISC 358-16 was followed by AISC 358-22. Many projects still reference the 2016 edition through the building code in force. Always use the edition your building code and project specification require.
